CARDBOARD MACHINE

The Odin Organ is a family-owned organ factory of barrel organs : www.odin.fr. The organs are mechanical, thanks to the rotation and the reading of the trousers on a perforated cardboard. The manufacturing of perforated cardboard which creates the different music is extremely rare and that's why we needed to create our own machine to punch notes in the cardboard appropriately. The final product was a machine (3-axis) and a software to convert music files (midi) into motor movements (Gcode) for the machine to drill.



2 months Jul / Aug 2015

Machine for perforating cardboard for the Odin Barrel Organ







© Copyright 2020, Antonin Odin
Paris, France.
